PRODUCT PARAMETERS
Cat.No.
8030122111
Work plate Dimension
184x184mm ( 7 inch )
Work plate material
Glass ceramic
Max. stirring quantity [H2O]
20L
Speed range
100-1500rpm，resolution±1rpm
Speed display
LCD
Temperature display
LCD
Heating temperature range
Room Temp.-550℃, increment 1℃
Temperature control accuracy
±1℃(<100℃) ±1%(>100℃)
Temperature display accuracy
±0.1℃
External temperature sensor
PT1000(accuracy ±0.2℃)
“Hot” warning
50℃
Overheating temperature protection
580℃
Motor type
Brushless DC motor
Stirring positions
1
Max. magnetic bar length
80mm
Data connector
RS232
Timer function
–
Protection class
IP21
Motor rating input
–
Motor rating output
10W
Power
1050W
Heating output
1000W
Voltage,Frequency
100-120V/200-240V，50/60Hz
Dimension [WxDxH]
215x360x112mm
Weight
5.3kg
Permissible ambient temperature
5-40℃
Permissible ambient humidity
80% RH
